Centrifugal blower VP-AS 400/N2/0,75 Es4

SKU:
906460.0401
Stock:

On backorder

Area of application: medium and low capacity and high pressure.
Type of blades: backward curved, negative.
Application: for pneumatic transport, using clean air. Can be used in foundries, food and chemical industries.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
VP-AS 400/N2/0,75 Es4

285-650

3000-2940

80

0.75

2845

57

55 kg
ModelVP-AS 400/N2/0,75 Es4
Air delivery, m³/h

285-650

Total pressure, Pa

3000-2940

Engine size

80

Power, kWt

0.75

Revolutions, rpm

2845

Noise, dB

57

Weight55 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
VP-AS 400/N2/0,75 Es4

285-650

3000-2940

80

0.75

2845

57

55 kg
ModelVP-AS 400/N2/0,75 Es4
Air delivery, m³/h

285-650

Total pressure, Pa

3000-2940

Engine size

80

Power, kWt

0.75

Revolutions, rpm

2845

Noise, dB

57

Weight55 kg
Fans features
L,м3/h 285 360 400 430 470 540 650
P,Pa 3000 3080 3100 3100 3080 3050 2940

Area of application: medium and low capacity and high pressure.
Type of blades: backward curved, negative.
Application: for pneumatic transport, using clean air. Can be used in foundries, food and chemical industries.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series VP-AS manufactured by Italian producer, assembled by Aton service LTD..
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), electric motor IP55, class of isolation F.
Options and special executions: protection screen on the inlet, inspection door, drain plug etc.
