Centrifugal blower GR-AS 1120/6/18,5 Es4

SKU:
906160.1124
Stock:

On backorder

Area of application: medium and low capacity, medium and high pressure.
Type of blades: backward curved.
Application: for transportation of clean and slightly dusty air, for extraction of fumes and gazes, fine dust, for pneumatic transport systems with clean air.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
GR-AS 1120/6/18,5 Es4

9360-32400

2460-1220

200

18.5

975

77

861 kg
ModelGR-AS 1120/6/18,5 Es4
Air delivery, m³/h

9360-32400

Total pressure, Pa

2460-1220

Engine size

200

Power, kWt

18.5

Revolutions, rpm

975

Noise, dB

77

Weight861 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
GR-AS 1120/6/18,5 Es4

9360-32400

2460-1220

200

18.5

975

77

861 kg
ModelGR-AS 1120/6/18,5 Es4
Air delivery, m³/h

9360-32400

Total pressure, Pa

2460-1220

Engine size

200

Power, kWt

18.5

Revolutions, rpm

975

Noise, dB

77

Weight861 kg
Fans features
L,м3/h 9360 10800 12600 14400 16200 18000 19800 21600 25200 28800 32400
P,Pa 2460 2430 2400 2360 2270 2170 2140 2000 1800 1550 1220

Area of application: medium and low capacity, medium and high pressure.
Type of blades: backward curved.
Application: for transportation of clean and slightly dusty air, for extraction of fumes and gazes, fine dust, for pneumatic transport systems with clean air.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series GR-AS manufactured by Italian producer, assembled by Aton service LTD.
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), Es 5 (direct drive, without supporting frame) electric motor IP55, class of isolation F.
Options and special executions: inspection door, drain plug, execution Es12 (V-belt drive), execution for high temperatures, sparkproof and explosion proof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Options

Photo SKU Product name Product description Price
906160.1124.01 GR ATEX3GD 1120/6/18,5 Es4 0.00
906000.0000.20 PI Inspection door 30.00
906000.0000.10 TS Drain plug 20.00
