Centrifugal blower MA-AS 551/11 Es4

SKU:
906200.0551
Stock:

On backorder

Area of application: medium and low capacity, medium and high pressure.
Type of blades: open.
Application: pneumatic transport of solid particles mixed with air, woodchips and sawdust; can be used for filamentous materials, that can block the impeller of backward curved type construction.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
MA-AS 551/11 Es4

1400-4500

5850-5600

160

11

2900

92

180 kg
ModelMA-AS 551/11 Es4
Air delivery, m³/h

1400-4500

Total pressure, Pa

5850-5600

Engine size

160

Power, kWt

11

Revolutions, rpm

2900

Noise, dB

92

Weight180 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
MA-AS 551/11 Es4

1400-4500

5850-5600

160

11

2900

92

180 kg
ModelMA-AS 551/11 Es4
Air delivery, m³/h

1400-4500

Total pressure, Pa

5850-5600

Engine size

160

Power, kWt

11

Revolutions, rpm

2900

Noise, dB

92

Weight180 kg
Fans features
L,м3/h 1400 1600 1800 2000 2250 2500 2750 3000 3250 3500 3750 4000 4500
P,Pa 5850 5900 5920 5940 5960 5980 5960 5940 5900 5840 5780 5720 5600

Area of application: medium and low capacity, medium and high pressure.
Type of blades: open.
Application: pneumatic transport of solid particles mixed with air, woodchips and sawdust; can be used for filamentous materials, that can block the impeller of backward curved type construction.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series MA-AS manufactured by Italian producer, assembled by Aton service LTD.
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), electric motor IP55, class of isolation F.
Options and special executions: spark-and dustproof execution, wear-resistant execution, execution Es12 (V-belt drive), execution for high temperatures, sparkproof and explosion proof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Options

Photo SKU Product name Product description Price
906200.0550.12 MA DE 550 0.00
