Area of application: low capacity and low pressure.
Type of blades: forwardcurved blades, type “sirocco”.
Application: for air or exhaust gazes movement, even slightly dusty.
| Model | Air delivery, m³/h | Total pressure, Pa | Engine size | Power, kWt | Revolutions, rpm | Noise, dB | Weight |
|---|---|---|---|---|---|---|---|
| MB-AS 352/2,2 Es4 | 1000-5000 | 880-1000 | 100 | 2,2 | 1410 | 79 | 60 kg |
| Model | MB-AS 352/2,2 Es4 |
|---|---|
| Air delivery, m³/h | 1000-5000 |
| Total pressure, Pa | 880-1000 |
| Engine size | 100 |
| Power, kWt | 2,2 |
| Revolutions, rpm | 1410 |
| Noise, dB | 79 |
| Weight | 60 kg |
| Model | Air delivery, m³/h | Total pressure, Pa | Engine size | Power, kWt | Revolutions, rpm | Noise, dB | Weight |
|---|---|---|---|---|---|---|---|
| MB-AS 352/2,2 Es4 | 1000-5000 | 880-1000 | 100 | 2,2 | 1410 | 79 | 60 kg |
| Model | MB-AS 352/2,2 Es4 |
|---|---|
| Air delivery, m³/h | 1000-5000 |
| Total pressure, Pa | 880-1000 |
| Engine size | 100 |
| Power, kWt | 2,2 |
| Revolutions, rpm | 1410 |
| Noise, dB | 79 |
| Weight | 60 kg |
| Fans features | |||||||||
| L,м3/h | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 |
| P,Pa | 880 | 830 | 840 | 850 | 890 | 940 | 970 | 990 | 1000 |
Area of application: low capacity and low pressure.
Type of blades: forwardcurved blades, type “sirocco”.
Application: for air or exhaust gazes movement, even slightly dusty.
Temperature of the fluid: till 80°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series MB-AS manufactured by Italian producer, assembled by Aton service LTD.
Unit of supply: blower execution Es4 (direct drive, motor on the supporting frame), execution Es 5 (direct drive, without supporting frame), electric motor IP55, class of isolation F.
Options and special executions: protection screen, drain plug, execution for high temperatures, sparkproof execution, etc.
| Photo | SKU | Product name | Product description | Price |
|---|---|---|---|---|
| 906310.0350.10 | MB-AS 350 Ant | 0.00 € |
