Area of application: low capacity and low pressure.
Type of blades: forwardcurved blades, type “sirocco”.
Application: for air or exhaust gazes movement, even slightly dusty.
| Model | Air delivery, m³/h | Total pressure, Pa | Engine size | Power, kWt | Revolutions, rpm | Noise, dB | Weight |
|---|---|---|---|---|---|---|---|
| MB-AS 402/4 Es4 | 2000-6500 | 1220-1290 | 112 | 4 | 1410 | 82 | 110 kg |
| Model | MB-AS 402/4 Es4 |
|---|---|
| Air delivery, m³/h | 2000-6500 |
| Total pressure, Pa | 1220-1290 |
| Engine size | 112 |
| Power, kWt | 4 |
| Revolutions, rpm | 1410 |
| Noise, dB | 82 |
| Weight | 110 kg |
| Model | Air delivery, m³/h | Total pressure, Pa | Engine size | Power, kWt | Revolutions, rpm | Noise, dB | Weight |
|---|---|---|---|---|---|---|---|
| MB-AS 402/4 Es4 | 2000-6500 | 1220-1290 | 112 | 4 | 1410 | 82 | 110 kg |
| Model | MB-AS 402/4 Es4 |
|---|---|
| Air delivery, m³/h | 2000-6500 |
| Total pressure, Pa | 1220-1290 |
| Engine size | 112 |
| Power, kWt | 4 |
| Revolutions, rpm | 1410 |
| Noise, dB | 82 |
| Weight | 110 kg |
| Fans features | ||||||||||
| L,м3/h | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 | 5500 | 6000 | 6500 |
| P,Pa | 1220 | 1210 | 1190 | 1200 | 1210 | 1220 | 1230 | 1260 | 1280 | 1290 |
Area of application: low capacity and low pressure.
Type of blades: forwardcurved blades, type “sirocco”.
Application: for air or exhaust gazes movement, even slightly dusty.
Temperature of the fluid: till 80°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series MB-AS manufactured by Italian producer, assembled by Aton service LTD.
Unit of supply: blower execution Es4 (direct drive, motor on the supporting frame), execution Es 5 (direct drive, without supporting frame), electric motor IP55, class of isolation F.
Options and special executions: protection screen, drain plug, execution for high temperatures, sparkproof execution, etc.
| Photo | SKU | Product name | Product description | Price |
|---|---|---|---|---|
| 906310.0400.10 | MB -AS400 Ant | 0.00 € |
