Centrifugal blower RH-AS 630/2R/30 Es4

SKU:
906110.0630
Stock:

On backorder

Area of application: high capacity and medium pressure.
Type of blades: backward curved.
Application: for clean or slightly dusty air.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
RH-AS 630/2R/30 Es4

10080-16200

5790-5250

200

30

2960

77

387 kg
ModelRH-AS 630/2R/30 Es4
Air delivery, m³/h

10080-16200

Total pressure, Pa

5790-5250

Engine size

200

Power, kWt

30

Revolutions, rpm

2960

Noise, dB

77

Weight387 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
RH-AS 630/2R/30 Es4

10080-16200

5790-5250

200

30

2960

77

387 kg
ModelRH-AS 630/2R/30 Es4
Air delivery, m³/h

10080-16200

Total pressure, Pa

5790-5250

Engine size

200

Power, kWt

30

Revolutions, rpm

2960

Noise, dB

77

Weight387 kg
Fans features
L,м3/h 10080 10800 12600 14400 16200
P,Pa 5790 5770 5650 5470 5250

Area of application: high capacity and medium pressure.
Type of blades: backward curved.
Application: for clean or slightly dusty air.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series RH-AS manufactured by Italian producer, assembled by Aton service LTD.
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), Es 5 (direct drive, without supporting frame) electric motor IP55, class of isolation F.
Options and special executions: inspection door, drain plug, execution Es12 (V-belt drive), execution for high temperatures, sparkproof and explosion proof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Options

Photo SKU Product name Product description Price
906000.0000.20 PI Inspection door 30.00
906110.0630.01 RH AS 630/2R/30 Es4 0.00
906000.0000.10 TS Drain plug 20.00
