Centrifugal blower RL-AS 1000/6R/18,5 Es4

SKU:
906150.1003
Stock:

On backorder

8,858.00

Area of application: very high capacity and low pressure.
Type of blades: backward curved.
Application: for transportation of clean and slightly dusty air, for different applications in industrial and civil areas, for industrial air-conditioning as well.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
RL-AS 1000/6R/18,5 Es4

18000-46800

1640-890

200

18.5

975

75

879 kg
ModelRL-AS 1000/6R/18,5 Es4
Air delivery, m³/h

18000-46800

Total pressure, Pa

1640-890

Engine size

200

Power, kWt

18.5

Revolutions, rpm

975

Noise, dB

75

Weight879 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
RL-AS 1000/6R/18,5 Es4

18000-46800

1640-890

200

18.5

975

75

879 kg
ModelRL-AS 1000/6R/18,5 Es4
Air delivery, m³/h

18000-46800

Total pressure, Pa

1640-890

Engine size

200

Power, kWt

18.5

Revolutions, rpm

975

Noise, dB

75

Weight879 kg
Fans features
L,м3/h 18000 19800 21600 25200 28800 32400 39600 39600 43200 46800
P,Pa 1640 1630 1620 1570 1490 1380 1210 1240 950 890

Area of application: very high capacity and low pressure.
Type of blades: backward curved.
Application: for transportation of clean and slightly dusty air, for different applications in industrial and civil areas, for industrial air-conditioning as well.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series RL-AS manufactured by Italian producer, assembled by Aton service LTD.
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), Es 5 (direct drive, without supporting frame) electric motor IP55, class of isolation F.
Options and special executions: inspection door, drain plug, execution Es12 (V-belt drive), execution for high temperatures, sparkproof and explosion proof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Options

Photo SKU Product name Product description Price
906000.0000.20 PI Inspection door 30.00
906150.1003.01 RL ATEX3GD 1000/6R/18,5 Es4 0.00
906000.0000.10 TS Drain plug 20.00
