Centrifugal blower RM-AS 1120/6/30 Es4

SKU:
906010.1124
Stock:

On backorder

Area of application: high capacity and medium pressure.
Type of blades: backward curved.
Application: dust extraction blower, suction and transportation of very dusty air, containing granular materials, wood chips and sawdust, excluding filamentous materials.
ve), execution for high temperatures, sparkproof and explosionproof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
RM-AS 1120/6/30 Es4

16200-46800

2500-1030

225

30

985

76

1,156 kg
ModelRM-AS 1120/6/30 Es4
Air delivery, m³/h

16200-46800

Total pressure, Pa

2500-1030

Engine size

225

Power, kWt

30

Revolutions, rpm

985

Noise, dB

76

Weight1,156 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
RM-AS 1120/6/30 Es4

16200-46800

2500-1030

225

30

985

76

1,156 kg
ModelRM-AS 1120/6/30 Es4
Air delivery, m³/h

16200-46800

Total pressure, Pa

2500-1030

Engine size

225

Power, kWt

30

Revolutions, rpm

985

Noise, dB

76

Weight1,156 kg
Fans features
L,м3/h 16200 18000 19800 21600 25200 28800 32400 36000 39600 43200
P,Pa 2500 2500 2480 2450 2350 2200 2010 1780 1550 1290

Area of application: high capacity and medium pressure.
Type of blades: backward curved.
Application: dust extraction blower, suction and transportation of very dusty air, containing granular materials, wood chips and sawdust, excluding filamentous materials.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series RM-AS manufactured by Italian producer, assembled by Aton service LTD..
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), Es 5 (irect drive, without supporting frame) electric motor IP55, class of isolation F.
Options and special executions: inspection door, drain plug, spark- and dustproof execution, wearresistant execution, execution Es12 (V-belt drive), execution for high temperatures, sparkproof and explosionproof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Options

Photo SKU Product name Product description Price
906000.0000.20 PI Inspection door 30.00
906010.1121.01 RM ATEX 1120/4R/75 Es4 0.00
906010.1120.10 RM DE 1120 Es4 1,498.00
906000.0000.10 TS Drain plug 20.00
