Centrifugal blower RM-AS 1250/6/45 Es4

SKU:
906010.1252
Stock:

On backorder

Area of application: high capacity and medium pressure.
Type of blades: backward curved.
Application: dust extraction blower, suction and transportation of very dusty air, containing granular materials, wood chips and sawdust, excluding filamentous materials.
ve), execution for high temperatures, sparkproof and explosionproof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
RM-AS 1250/6/45 Es4

21600-61200

3150-1600

280

45

990

78

1,915 kg
ModelRM-AS 1250/6/45 Es4
Air delivery, m³/h

21600-61200

Total pressure, Pa

3150-1600

Engine size

280

Power, kWt

45

Revolutions, rpm

990

Noise, dB

78

Weight1,915 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
RM-AS 1250/6/45 Es4

21600-61200

3150-1600

280

45

990

78

1,915 kg
ModelRM-AS 1250/6/45 Es4
Air delivery, m³/h

21600-61200

Total pressure, Pa

3150-1600

Engine size

280

Power, kWt

45

Revolutions, rpm

990

Noise, dB

78

Weight1,915 kg
Fans features
L,м3/h 21600 25200 28800 32400 36000 39600 43200 46800 46800 54000 61200
P,Pa 3150 3150 3110 3040 2930 2800 2640 1030 2460 2050 1600

Area of application: high capacity and medium pressure.
Type of blades: backward curved.
Application: dust extraction blower, suction and transportation of very dusty air, containing granular materials, wood chips and sawdust, excluding filamentous materials.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series RM-AS manufactured by Italian producer, assembled by Aton service LTD..
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), Es 5 (irect drive, without supporting frame) electric motor IP55, class of isolation F.
Options and special executions: inspection door, drain plug, spark- and dustproof execution, wearresistant execution, execution Es12 (V-belt drive), execution for high temperatures, sparkproof and explosionproof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Options

Photo SKU Product name Product description Price
906000.0000.20 PI Inspection door 30.00
906010.1252.01 RM ATEX 1250/6/45 Es4 0.00
906010.1250.10 RM DE 1250 Es4 1,666.00
906000.0000.10 TS Drain plug 20.00
