Centrifugal blower RM-AS 1400/6/75 Es4

SKU:
906010.1402
Stock:

On backorder

Area of application: high capacity and medium pressure.
Type of blades: backward curved.
Application: dust extraction blower, suction and transportation of very dusty air, containing granular materials, wood chips and sawdust, excluding filamentous materials.
ve), execution for high temperatures, sparkproof and explosionproof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
RM-AS 1400/6/75 Es4

32400-86400

3990-2030

315

75

995

81

2,346 kg
ModelRM-AS 1400/6/75 Es4
Air delivery, m³/h

32400-86400

Total pressure, Pa

3990-2030

Engine size

315

Power, kWt

75

Revolutions, rpm

995

Noise, dB

81

Weight2,346 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
RM-AS 1400/6/75 Es4

32400-86400

3990-2030

315

75

995

81

2,346 kg
ModelRM-AS 1400/6/75 Es4
Air delivery, m³/h

32400-86400

Total pressure, Pa

3990-2030

Engine size

315

Power, kWt

75

Revolutions, rpm

995

Noise, dB

81

Weight2,346 kg
Fans features
L,м3/h 32400 36000 39600 43200 46800 54000 61200 68400 76500 86400
P,Pa 3990 3990 3960 3900 3830 3610 3140 3010 2590 2030

Area of application: high capacity and medium pressure.
Type of blades: backward curved.
Application: dust extraction blower, suction and transportation of very dusty air, containing granular materials, wood chips and sawdust, excluding filamentous materials.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series RM-AS manufactured by Italian producer, assembled by Aton service LTD..
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), Es 5 (irect drive, without supporting frame) electric motor IP55, class of isolation F.
Options and special executions: inspection door, drain plug, spark- and dustproof execution, wearresistant execution, execution Es12 (V-belt drive), execution for high temperatures, sparkproof and explosionproof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Options

Photo SKU Product name Product description Price
906000.0000.20 PI Inspection door 30.00
906010.1402.01 RM ATEX 1400/6/75 Es4 0.00
906010.1400.10 RM DE 1400 Es4 2,240.00
906000.0000.10 TS Drain plug 20.00
