Centrifugal blower RM-AS 350/2/2,2 Es4

SKU:
906010.0352
Stock:

On backorder

1,097.00

Area of application: high capacity and medium pressure.
Type of blades: backward curved.
Application: dust extraction blower, suction and transportation of very dusty air, containing granular materials, wood chips and sawdust, excluding filamentous materials.
ve), execution for high temperatures, sparkproof and explosionproof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
RM-AS 350/2/2,2 Es4

1440-3960

2070-1240

90

2,2

2920

68

70 kg
ModelRM-AS 350/2/2,2 Es4
Air delivery, m³/h

1440-3960

Total pressure, Pa

2070-1240

Engine size

90

Power, kWt

2,2

Revolutions, rpm

2920

Noise, dB

68

Weight70 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
RM-AS 350/2/2,2 Es4

1440-3960

2070-1240

90

2,2

2920

68

70 kg
ModelRM-AS 350/2/2,2 Es4
Air delivery, m³/h

1440-3960

Total pressure, Pa

2070-1240

Engine size

90

Power, kWt

2,2

Revolutions, rpm

2920

Noise, dB

68

Weight70 kg
Fans features
L,м3/h 1440 1620 1800 2160 2520 2880 3240 3600 3960
P,Pa 2070 2070 2070 2030 1950 1830 1680 1480 1240

Area of application: high capacity and medium pressure.
Type of blades: backward curved.
Application: dust extraction blower, suction and transportation of very dusty air, containing granular materials, wood chips and sawdust, excluding filamentous materials.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series RM-AS manufactured by Italian producer, assembled by Aton service LTD..
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), Es 5 (irect drive, without supporting frame) electric motor IP55, class of isolation F.
Options and special executions: inspection door, drain plug, spark- and dustproof execution, wearresistant execution, execution Es12 (V-belt drive), execution for high temperatures, sparkproof and explosionproof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Options

Photo SKU Product name Product description Price
906000.0000.20 PI Inspection door 30.00
906010.0352.01 RM ATEX 350/2/2,2 Es4 0.00
906010.0350.10 RM DE 350 Es4 357.00
906000.0000.10 TS Drain plug 20.00
