Centrifugal blower RM-AS 800/6/5,5 Es4

SKU:
906010.0804
Stock:

On backorder

Area of application: high capacity and medium pressure.
Type of blades: backward curved.
Application: dust extraction blower, suction and transportation of very dusty air, containing granular materials, wood chips and sawdust, excluding filamentous materials.
ve), execution for high temperatures, sparkproof and explosionproof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
RM-AS 800/6/5,5 Es4

5400-16200

1170-480

132

5,5

960

68

395 kg
ModelRM-AS 800/6/5,5 Es4
Air delivery, m³/h

5400-16200

Total pressure, Pa

1170-480

Engine size

132

Power, kWt

5,5

Revolutions, rpm

960

Noise, dB

68

Weight395 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
RM-AS 800/6/5,5 Es4

5400-16200

1170-480

132

5,5

960

68

395 kg
ModelRM-AS 800/6/5,5 Es4
Air delivery, m³/h

5400-16200

Total pressure, Pa

1170-480

Engine size

132

Power, kWt

5,5

Revolutions, rpm

960

Noise, dB

68

Weight395 kg
Fans features
L,м3/h 5400 6120 7200 7920 9000 10080 10800 12600 14400
P,Pa 1170 1170 1160 1140 1080 1030 980 850 650

Area of application: high capacity and medium pressure.
Type of blades: backward curved.
Application: dust extraction blower, suction and transportation of very dusty air, containing granular materials, wood chips and sawdust, excluding filamentous materials.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series RM-AS manufactured by Italian producer, assembled by Aton service LTD..
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), Es 5 (irect drive, without supporting frame) electric motor IP55, class of isolation F.
Options and special executions: inspection door, drain plug, spark- and dustproof execution, wearresistant execution, execution Es12 (V-belt drive), execution for high temperatures, sparkproof and explosionproof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Options

Photo SKU Product name Product description Price
906000.0000.20 PI Inspection door 30.00
906010.0801.01 RM ATEX 800/4R/15 Es4 0.00
906010.0800.10 RM DE 800 Es4 721.00
906010.0800.11 RM HE 800 Es4 1,442.00
906000.0000.10 TS Drain plug 20.00
