Centrifugal blower RM-AS 900/6/11 Es4

SKU:
906010.0904
Stock:

On backorder

Area of application: high capacity and medium pressure.
Type of blades: backward curved.
Application: dust extraction blower, suction and transportation of very dusty air, containing granular materials, wood chips and sawdust, excluding filamentous materials.
ve), execution for high temperatures, sparkproof and explosionproof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
RM-AS 900/6/11 Es4

7920-21600

1560-800

160

11

970

71

531 kg
ModelRM-AS 900/6/11 Es4
Air delivery, m³/h

7920-21600

Total pressure, Pa

1560-800

Engine size

160

Power, kWt

11

Revolutions, rpm

970

Noise, dB

71

Weight531 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
RM-AS 900/6/11 Es4

7920-21600

1560-800

160

11

970

71

531 kg
ModelRM-AS 900/6/11 Es4
Air delivery, m³/h

7920-21600

Total pressure, Pa

1560-800

Engine size

160

Power, kWt

11

Revolutions, rpm

970

Noise, dB

71

Weight531 kg
Fans features
L,м3/h 7920 9000 10080 10800 12600 14400 16200 18000 19800 21600
P,Pa 1560 1560 1530 1510 1470 1330 1250 1100 980 800

Area of application: high capacity and medium pressure.
Type of blades: backward curved.
Application: dust extraction blower, suction and transportation of very dusty air, containing granular materials, wood chips and sawdust, excluding filamentous materials.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series RM-AS manufactured by Italian producer, assembled by Aton service LTD..
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), Es 5 (irect drive, without supporting frame) electric motor IP55, class of isolation F.
Options and special executions: inspection door, drain plug, spark- and dustproof execution, wearresistant execution, execution Es12 (V-belt drive), execution for high temperatures, sparkproof and explosionproof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Options

Photo SKU Product name Product description Price
906000.0000.20 PI Inspection door 30.00
906010.0901.01 RM ATEX 900/4R/30 Es4 0.00
906010.0900.10 RM DE 900 Es4 812.00
906010.0900.11 RM HE 800 Es4 1,540.00
906000.0000.10 TS Drain plug 20.00
