Centrifugal blower VC-AS 710/N2/11 Es4

SKU:
906450.0713
Stock:

On backorder

Area of application: medium and low capacity and high pressure.
Type of blades: backward curved, negative.
Application: for pneumatic transport, using clean air. Can be used in foundries, food and chemical industries.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
VC-AS 710/N2/11 Es4

400-2520

9830-9360

160

11

2940

71

238 kg
ModelVC-AS 710/N2/11 Es4
Air delivery, m³/h

400-2520

Total pressure, Pa

9830-9360

Engine size

160

Power, kWt

11

Revolutions, rpm

2940

Noise, dB

71

Weight238 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
VC-AS 710/N2/11 Es4

400-2520

9830-9360

160

11

2940

71

238 kg
ModelVC-AS 710/N2/11 Es4
Air delivery, m³/h

400-2520

Total pressure, Pa

9830-9360

Engine size

160

Power, kWt

11

Revolutions, rpm

2940

Noise, dB

71

Weight238 kg
Fans features
L,м3/h 400 430 470 540 650 720 790 865 935 1080 1225 1370 1440 1620 1800 2160 2520
P,Pa 9830 9870 9910 9980 10070 10120 10160 10210 10240 10310 10350 10370 10360 10320 10260 9900 9360

Area of application: medium and low capacity and high pressure.
Type of blades: backward curved, negative.
Application: for pneumatic transport, using clean air. Can be used in foundries, food and chemical industries.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series VC-AS manufactured by Italian producer, assembled by Aton service LTD..
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), electric motor IP55, class of isolation F.
Options and special executions: protection screen on the inlet, inspection door, drain plug etc.
