Centrifugal blower VG-AS 800/N2/37 Es4

SKU:
906420.0802
Stock:

On backorder

6,745.20

Area of application: medium and low capacity and high pressure.
Type of blades: backward curved, negative.
Application: for pneumatic transport, using clean air. Can be used in foundries, food and chemical industries.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
VG-AS 800/N2/37 Es4

4320-7920

14000-13200

200

37

2970

77

439 kg
ModelVG-AS 800/N2/37 Es4
Air delivery, m³/h

4320-7920

Total pressure, Pa

14000-13200

Engine size

200

Power, kWt

37

Revolutions, rpm

2970

Noise, dB

77

Weight439 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
VG-AS 800/N2/37 Es4

4320-7920

14000-13200

200

37

2970

77

439 kg
ModelVG-AS 800/N2/37 Es4
Air delivery, m³/h

4320-7920

Total pressure, Pa

14000-13200

Engine size

200

Power, kWt

37

Revolutions, rpm

2970

Noise, dB

77

Weight439 kg
Fans features
L,м3/h 4320 4680 5400 6120 7200 7920
P,Pa 14000 14020 14000 13880 13440 13200

Area of application: medium and low capacity and high pressure.
Type of blades: backward curved, negative.
Application: for pneumatic transport, using clean air. Can be used in foundries, food and chemical industries.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series VP-AS manufactured by Italian producer, assembled by Aton service LTD..
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), electric motor IP55, class of isolation F.
Options and special executions: protection screen on the inlet, inspection door, drain plug etc.
