Centrifugal blower VG-AS 800/N2R/30 Es4

SKU:
906420.0800
Stock:

On backorder

Area of application: medium and low capacity and high pressure.
Type of blades: backward curved, negative.
Application: for pneumatic transport, using clean air. Can be used in foundries, food and chemical industries.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
VG-AS 800/N2R/30 Es4

3600-7200

12600-11690

200

30

2970

76

472 kg
ModelVG-AS 800/N2R/30 Es4
Air delivery, m³/h

3600-7200

Total pressure, Pa

12600-11690

Engine size

200

Power, kWt

30

Revolutions, rpm

2970

Noise, dB

76

Weight472 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
VG-AS 800/N2R/30 Es4

3600-7200

12600-11690

200

30

2970

76

472 kg
ModelVG-AS 800/N2R/30 Es4
Air delivery, m³/h

3600-7200

Total pressure, Pa

12600-11690

Engine size

200

Power, kWt

30

Revolutions, rpm

2970

Noise, dB

76

Weight472 kg
Fans features
L,м3/h 3600 3960 4320 4680 5400 6120 7200
P,Pa 12600 12640 12650 12630 12490 12230 11690

Area of application: medium and low capacity and high pressure.
Type of blades: backward curved, negative.
Application: for pneumatic transport, using clean air. Can be used in foundries, food and chemical industries.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series VP-AS manufactured by Italian producer, assembled by Aton service LTD..
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), electric motor IP55, class of isolation F.
Options and special executions: protection screen on the inlet, inspection door, drain plug etc.
