Centrifugal blower VI-AS 500/N2R/4 Es4

SKU:
906440.0500
Stock:

On backorder

Area of application: medium and low capacity and high pressure.
Type of blades: backward curved, negative.
Application: for pneumatic transport, using clean air. Can be used in foundries, food and chemical industries.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
VI-AS 500/N2R/4 Es4

1800-3960

3740-2820

112

4

2940

67

94 kg
ModelVI-AS 500/N2R/4 Es4
Air delivery, m³/h

1800-3960

Total pressure, Pa

3740-2820

Engine size

112

Power, kWt

4

Revolutions, rpm

2940

Noise, dB

67

Weight94 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
VI-AS 500/N2R/4 Es4

1800-3960

3740-2820

112

4

2940

67

94 kg
ModelVI-AS 500/N2R/4 Es4
Air delivery, m³/h

1800-3960

Total pressure, Pa

3740-2820

Engine size

112

Power, kWt

4

Revolutions, rpm

2940

Noise, dB

67

Weight94 kg
Fans features
L,м3/h 1800 2160 2520 2880 3240 3600 3960
P,Pa 3740 3700 3580 3400 3260 3110 2820

Area of application: medium and low capacity and high pressure.
Type of blades: backward curved, negative.
Application: for pneumatic transport, using clean air. Can be used in foundries, food and chemical industries.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series VI-AS manufactured by Italian producer, assembled by Aton service LTD..
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), electric motor IP55, class of isolation F.
Options and special executions: protection screen on the inlet, inspection door, drain plug etc.
