Centrifugal blower VP-AS 630/N2/5,5 Es4

SKU:
906460.0632
Stock:

On backorder

Area of application: medium and low capacity and high pressure.
Type of blades: backward curved, negative.
Application: for pneumatic transport, using clean air. Can be used in foundries, food and chemical industries.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
VP-AS 630/N2/5,5 Es4

720-1620

7850-8250

132

5,5

2950

66

145 kg
ModelVP-AS 630/N2/5,5 Es4
Air delivery, m³/h

720-1620

Total pressure, Pa

7850-8250

Engine size

132

Power, kWt

5,5

Revolutions, rpm

2950

Noise, dB

66

Weight145 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
VP-AS 630/N2/5,5 Es4

720-1620

7850-8250

132

5,5

2950

66

145 kg
ModelVP-AS 630/N2/5,5 Es4
Air delivery, m³/h

720-1620

Total pressure, Pa

7850-8250

Engine size

132

Power, kWt

5,5

Revolutions, rpm

2950

Noise, dB

66

Weight145 kg
Fans features
L,м3/h 720 790 865 935 1080 1225 1370 1440 1620
P,Pa 7850 7920 8000 8030 8060 8100 8160 8200 8250

Area of application: medium and low capacity and high pressure.
Type of blades: backward curved, negative.
Application: for pneumatic transport, using clean air. Can be used in foundries, food and chemical industries.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series VP-AS manufactured by Italian producer, assembled by Aton service LTD..
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), electric motor IP55, class of isolation F.
Options and special executions: protection screen on the inlet, inspection door, drain plug etc.
