Centrifugal blower VP-AS 800/N2R/15 Es4

SKU:
906460.0800
Stock:

On backorder

Area of application: medium and low capacity and high pressure.
Type of blades: backward curved, negative.
Application: for pneumatic transport, using clean air. Can be used in foundries, food and chemical industries.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
VP-AS 800/N2R/15 Es4

1370-3240

11520-12080

160

15

2960

75

256 kg
ModelVP-AS 800/N2R/15 Es4
Air delivery, m³/h

1370-3240

Total pressure, Pa

11520-12080

Engine size

160

Power, kWt

15

Revolutions, rpm

2960

Noise, dB

75

Weight256 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
VP-AS 800/N2R/15 Es4

1370-3240

11520-12080

160

15

2960

75

256 kg
ModelVP-AS 800/N2R/15 Es4
Air delivery, m³/h

1370-3240

Total pressure, Pa

11520-12080

Engine size

160

Power, kWt

15

Revolutions, rpm

2960

Noise, dB

75

Weight256 kg
Fans features
L,м3/h 1370 1440 1620 1800 2160 2520 2880 3240
P,Pa 11520 11560 11620 11760 11890 11980 12080 12080

Area of application: medium and low capacity and high pressure.
Type of blades: backward curved, negative.
Application: for pneumatic transport, using clean air. Can be used in foundries, food and chemical industries.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series VP-AS manufactured by Italian producer, assembled by Aton service LTD..
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), electric motor IP55, class of isolation F.
Options and special executions: protection screen on the inlet, inspection door, drain plug etc.
