Centrifugal blower ZB-AS 450/P2/3 Es4

SKU:
906340.0450
Stock:

On backorder

Area of application: medium and low capacity, medium and high pressure.
Type of blades: open.
Application: pneumatic transport of solid particles mixed with air, woodchips and sawdust; can be used for filamentous materials, that can block the impeller of backward curved type construction.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
ZB-AS 450/P2/3 Es4

650-1620

3720-3620

100

3

2920

72

70 kg
ModelZB-AS 450/P2/3 Es4
Air delivery, m³/h

650-1620

Total pressure, Pa

3720-3620

Engine size

100

Power, kWt

3

Revolutions, rpm

2920

Noise, dB

72

Weight70 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
ZB-AS 450/P2/3 Es4

650-1620

3720-3620

100

3

2920

72

70 kg
ModelZB-AS 450/P2/3 Es4
Air delivery, m³/h

650-1620

Total pressure, Pa

3720-3620

Engine size

100

Power, kWt

3

Revolutions, rpm

2920

Noise, dB

72

Weight70 kg
Fans features
L,м3/h 650 720 790 865 935 1080 1225 1370 1440 1620
P,Pa 3720 3720 3700 3700 3680 3680 3670 3670 3670 3620

Area of application: medium and low capacity, medium and high pressure.
Type of blades: open.
Application: pneumatic transport of solid particles mixed with air, woodchips and sawdust; can be used for filamentous materials, that can block the impeller of backward curved type construction.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series ZB-AS manufactured by Italian producer, assembled by Aton service LTD.
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), electric motor IP55, class of isolation F.
Options and special executions: inspection door, drain plug, spark-and dustproof execution, wear-resistant execution, execution Es12 (V-belt drive), execution for high temperatures, sparkproof and explosion proof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Options

Photo SKU Product name Product description Price
906000.0000.20 PI Inspection door 30.00
906000.0000.10 TS Drain plug 20.00
906340.0450.10 ZB CE 450 189.00
906340.0450.11 ZB HE450 576.00
