Centrifugal blower ZB-AS 630/P2/15 Es4

SKU:
906340.0630
Stock:

On backorder

4,179.60

Area of application: medium and low capacity, medium and high pressure.
Type of blades: open.
Application: pneumatic transport of solid particles mixed with air, woodchips and sawdust; can be used for filamentous materials, that can block the impeller of backward curved type construction.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
ZB-AS 630/P2/15 Es4

1440-4320

7650-7660

160

15

2960

80

182 kg
ModelZB-AS 630/P2/15 Es4
Air delivery, m³/h

1440-4320

Total pressure, Pa

7650-7660

Engine size

160

Power, kWt

15

Revolutions, rpm

2960

Noise, dB

80

Weight182 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
ZB-AS 630/P2/15 Es4

1440-4320

7650-7660

160

15

2960

80

182 kg
ModelZB-AS 630/P2/15 Es4
Air delivery, m³/h

1440-4320

Total pressure, Pa

7650-7660

Engine size

160

Power, kWt

15

Revolutions, rpm

2960

Noise, dB

80

Weight182 kg
Fans features
L,м3/h 1440 1620 1800 2160 2520 2880 3240 3600 3960 4320
P,Pa 7650 7670 7680 7690 7720 7740 7750 7750 7730 7660

Area of application: medium and low capacity, medium and high pressure.
Type of blades: open.
Application: pneumatic transport of solid particles mixed with air, woodchips and sawdust; can be used for filamentous materials, that can block the impeller of backward curved type construction.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series ZB-AS manufactured by Italian producer, assembled by Aton service LTD.
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), electric motor IP55, class of isolation F.
Options and special executions: inspection door, drain plug, spark-and dustproof execution, wear-resistant execution, execution Es12 (V-belt drive), execution for high temperatures, sparkproof and explosion proof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Options

Photo SKU Product name Product description Price
906000.0000.20 PI Inspection door 30.00
906000.0000.10 TS Drain plug 20.00
906340.0630.10 ZB CE 630 275.00
906340.0630.11 ZB HE630 861.00
