Centrifugal blower ZB-AS 800/P2/55 Es4

SKU:
906340.0802
Stock:

On backorder

Area of application: medium and low capacity, medium and high pressure.
Type of blades: open.
Application: pneumatic transport of solid particles mixed with air, woodchips and sawdust; can be used for filamentous materials, that can block the impeller of backward curved type construction.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
ZB-AS 800/P2/55 Es4

3960-10600

12410-12130

250

55

2970

88

661 kg
ModelZB-AS 800/P2/55 Es4
Air delivery, m³/h

3960-10600

Total pressure, Pa

12410-12130

Engine size

250

Power, kWt

55

Revolutions, rpm

2970

Noise, dB

88

Weight661 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
ZB-AS 800/P2/55 Es4

3960-10600

12410-12130

250

55

2970

88

661 kg
ModelZB-AS 800/P2/55 Es4
Air delivery, m³/h

3960-10600

Total pressure, Pa

12410-12130

Engine size

250

Power, kWt

55

Revolutions, rpm

2970

Noise, dB

88

Weight661 kg
Fans features
L,м3/h 3960 4320 4680 5400 6120 7200 7920 9000 10600
P,Pa 12410 12410 12410 12440 12460 12470 12470 12330 12130

Area of application: medium and low capacity, medium and high pressure.
Type of blades: open.
Application: pneumatic transport of solid particles mixed with air, woodchips and sawdust; can be used for filamentous materials, that can block the impeller of backward curved type construction.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series ZB-AS manufactured by Italian producer, assembled by Aton service LTD.
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), electric motor IP55, class of isolation F.
Options and special executions: inspection door, drain plug, spark-and dustproof execution, wear-resistant execution, execution Es12 (V-belt drive), execution for high temperatures, sparkproof and explosion proof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Options

Photo SKU Product name Product description Price
906000.0000.20 PI Inspection door 30.00
906000.0000.10 TS Drain plug 20.00
906340.0800.10 ZB CE 800 382.00
906340.0800.11 ZB HE800 1,688.00
