Centrifugal blower ZM-AS 560/4R/4 Es4

SKU:
906230.0561
Stock:

On backorder

Area of application: medium and low capacity, medium and high pressure.
Type of blades: open.
Application: pneumatic transport of solid particles mixed with air, woodchips and sawdust; can be used for filamentous materials, that can block the impeller of backward curved type construction.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
ZM-AS 560/4R/4 Es4

2880-6120

1190-940

112

4

1440

69

156 kg
ModelZM-AS 560/4R/4 Es4
Air delivery, m³/h

2880-6120

Total pressure, Pa

1190-940

Engine size

112

Power, kWt

4

Revolutions, rpm

1440

Noise, dB

69

Weight156 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
ZM-AS 560/4R/4 Es4

2880-6120

1190-940

112

4

1440

69

156 kg
ModelZM-AS 560/4R/4 Es4
Air delivery, m³/h

2880-6120

Total pressure, Pa

1190-940

Engine size

112

Power, kWt

4

Revolutions, rpm

1440

Noise, dB

69

Weight156 kg
Fans features
L,м3/h 2880 3240 3600 3960 4320 4680 5400 6120
P,Pa 1190 1170 1150 1140 1100 1070 1020 940

Area of application: medium and low capacity, medium and high pressure.
Type of blades: open.
Application: pneumatic transport of solid particles mixed with air, woodchips and sawdust; can be used for filamentous materials, that can block the impeller of backward curved type construction.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series ZM-AS manufactured by Italian producer, assembled by Aton service LTD.
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), electric motor IP55, class of isolation F.
Options and special executions: inspection door, drain plug, spark-and dustproof execution, wear-resistant execution, execution Es12 (V-belt drive), execution for high temperatures, sparkproof and explosion proof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Options

Photo SKU Product name Product description Price
906000.0000.20 PI Inspection door 30.00
906000.0000.10 TS Drain plug 20.00
906230.0560.10 ZM CE 560 315.00
906230.0560.11 ZM HE 560 817.00
