Centrifugal blower ZM-AS 630/4/11 Es4

SKU:
906230.0632
Stock:

On backorder

3,812.40

Area of application: medium and low capacity, medium and high pressure.
Type of blades: open.
Application: pneumatic transport of solid particles mixed with air, woodchips and sawdust; can be used for filamentous materials, that can block the impeller of backward curved type construction.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
ZM-AS 630/4/11 Es4

3960-10080

1680-1290

160

11

1460

73

250 kg
ModelZM-AS 630/4/11 Es4
Air delivery, m³/h

3960-10080

Total pressure, Pa

1680-1290

Engine size

160

Power, kWt

11

Revolutions, rpm

1460

Noise, dB

73

Weight250 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
ZM-AS 630/4/11 Es4

3960-10080

1680-1290

160

11

1460

73

250 kg
ModelZM-AS 630/4/11 Es4
Air delivery, m³/h

3960-10080

Total pressure, Pa

1680-1290

Engine size

160

Power, kWt

11

Revolutions, rpm

1460

Noise, dB

73

Weight250 kg
Fans features
L,м3/h 3960 4320 4680 5400 6120 7200 7920 9000 10080
P,Pa 1680 1670 1660 1640 1600 1530 1470 1390 1290

Area of application: medium and low capacity, medium and high pressure.
Type of blades: open.
Application: pneumatic transport of solid particles mixed with air, woodchips and sawdust; can be used for filamentous materials, that can block the impeller of backward curved type construction.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series ZM-AS manufactured by Italian producer, assembled by Aton service LTD.
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), electric motor IP55, class of isolation F.
Options and special executions: inspection door, drain plug, spark-and dustproof execution, wear-resistant execution, execution Es12 (V-belt drive), execution for high temperatures, sparkproof and explosion proof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Options

Photo SKU Product name Product description Price
906000.0000.20 PI Inspection door 30.00
906000.0000.10 TS Drain plug 20.00
906230.0630.10 ZM CE 630 342.00
906230.0630.11 ZM HE 630 959.00
