Centrifugal blower ZM-AS 900/4R/37 Es4

SKU:
906230.0901
Stock:

On backorder

7,862.40

Area of application: medium and low capacity, medium and high pressure.
Type of blades: open.
Application: pneumatic transport of solid particles mixed with air, woodchips and sawdust; can be used for filamentous materials, that can block the impeller of backward curved type construction.

Additional information

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
ZM-AS 900/4R/37 Es4

10800-28800

3240-2340

225

37

1470

82

782 kg
ModelZM-AS 900/4R/37 Es4
Air delivery, m³/h

10800-28800

Total pressure, Pa

3240-2340

Engine size

225

Power, kWt

37

Revolutions, rpm

1470

Noise, dB

82

Weight782 kg

Description

ModelAir delivery, m³/hTotal pressure, PaEngine sizePower, kWtRevolutions, rpmNoise, dBWeight
ZM-AS 900/4R/37 Es4

10800-28800

3240-2340

225

37

1470

82

782 kg
ModelZM-AS 900/4R/37 Es4
Air delivery, m³/h

10800-28800

Total pressure, Pa

3240-2340

Engine size

225

Power, kWt

37

Revolutions, rpm

1470

Noise, dB

82

Weight782 kg
Fans features
L,м3/h 10800 12600 14400 16200 18000 19800 21600 25200 28800
P,Pa 3240 3210 3140 3060 3000 2900 2810 2600 2340

Area of application: medium and low capacity, medium and high pressure.
Type of blades: open.
Application: pneumatic transport of solid particles mixed with air, woodchips and sawdust; can be used for filamentous materials, that can block the impeller of backward curved type construction.
Temperature of the fluid: till 60°C for standard execution, for higher temperatures special execution of the blower is required.
Construction’s specification: stable construction made of sheet metal. Blower is covered by powder paint, baked at 200°C with the average thickness of соating 70 mc, the impeller is covered by epoxy grounding.
Blower is statically and dynamically balanced.
Impeller and motor produced in Italy, correspond to quality norms of EU.
Series ZM-AS manufactured by Italian producer, assembled by Aton service LTD.
Unit of supply: blower execution Es 4 (direct drive, motor on supporting frame), electric motor IP55, class of isolation F.
Options and special executions: inspection door, drain plug, spark-and dustproof execution, wear-resistant execution, execution Es12 (V-belt drive), execution for high temperatures, sparkproof and explosion proof execution (АTEX 3GD, АTEX 2G, АTEX 2D), etc.

Options

Photo SKU Product name Product description Price
906000.0000.20 PI Inspection door 30.00
906000.0000.10 TS Drain plug 20.00
906230.0900.10 ZM CE 900 451.00
906230.0900.11 ZM HE 900 1,090.00
