Side-channel blower SC501MF2.2T

SKU:
706500.0502
Stock:

On backorder

Request a price

Construction of blades of side-channel blowers is based on the principle of side passages.

Additional information

ModelPower, kWtInjection. Capacity Max, m³/hourInjection. Pressure Max, mBarDepression. Capacity Max, m³/hourDepression. Pressure Max, mBarTypeMotorNoise, dBWeight
SC501MF2.2T

2.2

210

275

210

225

Single stage

Three-phase

64

25 kg
ModelSC501MF2.2T
Power, kWt

2.2

Injection. Capacity Max, m³/hour

210

Injection. Pressure Max, mBar

275

Depression. Capacity Max, m³/hour

210

Depression. Pressure Max, mBar

225

Type

Single stage

Motor

Three-phase

Noise, dB

64

Weight25 kg

Description

ModelPower, kWtInjection. Capacity Max, m³/hourInjection. Pressure Max, mBarDepression. Capacity Max, m³/hourDepression. Pressure Max, mBarTypeMotorNoise, dBWeight
SC501MF2.2T

2.2

210

275

210

225

Single stage

Three-phase

64

25 kg
ModelSC501MF2.2T
Power, kWt

2.2

Injection. Capacity Max, m³/hour

210

Injection. Pressure Max, mBar

275

Depression. Capacity Max, m³/hour

210

Depression. Pressure Max, mBar

225

Type

Single stage

Motor

Three-phase

Noise, dB

64

Weight25 kg

Construction of blades of side-channel blowers is based on the principle of side passages. Side-channel blowers are working both for vacuum and for compression and are intended for constant work. The impeller is installed directly on the shaft of the motor; all moving parts are balanced, ensuring the total absence of vibration. Casting construction provides maximum rigidness and easiness in usage.
Equipment is produced in Italy, corresponds to quality norms of EU.
